Certified Pre-Owned 2019 X5 – HANCOCK 2.0 – is now on sale!
Certified Pre-Owned 2019 X5 “HANCOCK 2.0”
is now on sale!
2019 X5: excellent condition, premium options and customizations
Experience luxury on the water with this impeccably maintained 2019 X5, offered in excellent condition and featuring a wide array of premium options and customizations.
The current owners are upgrading to the new Xquisite 54′ E-PLUS, making this stunning vessel available through Xquisite Yachts’ exclusive Certified Pre-Owned Program.
This program ensures peace of mind with a comprehensive technical inspection and servicing of the yacht and all its systems. As part of this exceptional package, the new owner will enjoy one week of onboard training and benefit from a 90-day extended Xquisite Yachts warranty.
Don’t miss this opportunity to own a beautifully maintained yacht backed by unmatched support and expertise.
- Certified Pre-Owned
- 90-Day Extended Warranty
- Complete Technical Checkup
- Onboard Training
Unique Extras & Premium Options!
Completely checked and comes with our 90-Day Extended Warranty!
She’s offered in our
Certified Pre-Owned Program
Location: Freeport, Bahamas
Port engine hours: 1790 h
Starboard engine hours: 1781 h- Generator hours: 908 h
Price: US$ 1,250,000 (EU VAT paid!)
A whole week of onboard training for the new lucky owner!
Xquisite X5 SAIL Specifications & Unique Extras below
Xquisite X5 SAIL Specifications and Unique Extras below
CPO 2019 X5 Exterior
CPO 2019 X5 Exterior
CPO 2019 X5 Saloon
CPO 2019 X5 Saloon
CPO 2019 X5 Saloon
CPO 2019 X5 Saloon
CPO 2019 X5 Saloon
CPO 2019 X5 Saloon
CPO 2019 X5 Saloon
CPO 2019 X5 Saloon
CPO 2019 X5 Saloon
CPO 2019 X5 Saloon
CPO 2019 X5 Saloon
CPO 2019 X5 Saloon
CPO 2019 X5 – Starboard Master Cabin
CPO 2019 X5 – Starboard Master Cabin
CPO 2019 X5 – Starboard Master Cabin
CPO 2019 X5 – Starboard Master Cabin
CPO 2019 X5 – Starboard Master Cabin
CPO 2019 X5 – Starboard Master Cabin
CPO 2019 X5 – Starboard Master Cabin
CPO 2019 X5 – Starboard Master Cabin
CPO 2019 X5 – Port Forward Cabin
CPO 2019 X5 – Port Forward Cabin
CPO 2019 X5 – Port Forward Cabin
CPO 2019 X5 – Port Forward Cabin
CPO 2019 X5 – Port Aft Cabin
CPO 2019 X5 – Port Aft Cabin
CPO 2019 X5 – Port Aft Cabin
X5 – HANCOCK 2.0 – Specs & Extras
-
LAYOUT
OWNER VERSION – 3x cabins and 3x en-suite heads/bathrooms Specifications
Length overall 15.44 m 50.64 ft Length waterline 15.15 m 49.69 ft Beam 8 m 24.24 ft Draft 1.35 m 4.43 ft Bridge deck clearance Light Craft 1 m 3.28 ft Mast height above waterline 24 m 78.72 ft Sail Area
Sail Area – Mainsail 100 m² 1076 sf Sail Area-Reacher 83 m² 893 sf Sail Area-Jib 36 m² 387 sf Engines 2 x 80 HP 2 x 80 HP Fresh water (4 x 215Ltr tanks) 860 Ltr 226 gal Diesel (2 x 395Ltr tanks) 790 Ltr 208 gal CE Certified Category A Category A Displacement (mlcc) 21000 kg 46200 lbs UNIQUE EXTRAS
COMFORT PACKAGE
Gas BBQ on transom Cotton pascale, quilted double bed fitted mattress protectors Fendertex – inflatable fenders with custom logo (8 units) Canopy shade for foredeck and 2x large bean bacg (or foldable deck seats) Four button remote for C-Zone system ELECTRONICS UPGRADE
Additional 2nd Garmin GMI 20 repeater screen at inside nav station Garmin AIS 600 transceiver (receiver is standard) Garmin forward looking sounder Hailer installed on spreaders and connected to VHF radio Garmin Sirius XM receiver (USA only) ELECTRICAL UPGRADE
Batteries upgrade to 1080 Ah Li-ion Additional 900W solar panels with separate Mastervolt MPPT charge controller fitted on targa ENTERTAINMENT PACKAGE
Colour television – 3x Samsung 32″ LED TV’s in cabins 1x TV in master cabin Bose home theater sound system in saloon 2x Bose speakers to be fitted on spreaders 4 x Underwater LED lights COMMUNICATIONS PACKAGE
Cellular Modem / WiFi Router Antenna System Iridium Go with external aerial on spreader SATELLITE TV SYSTEM
KVH TV5 satellite TV system SATELLITE BROADBAND INTERNET SYSTEM
KVH TracPhone V3ip antenna system FLEXITEEK DECKING
Flexiteek on cockpit floor, steps to helm station and helm station floor (Estimtated at 50% of total area) DOWNWIND SAIL
Wingaker – 212m² with Easy Snuffer and Cruising bag (Pre-install blocks only) PROPELLER UPGRADE
Gori 3 blade folding propellers with rope cutters WINCH UPGRADE
Harken 3 speed electric winches (in lieu of 2 speed) WATERMAKER UPGRADE
Water maker – Newport NP-MK IIZ-1000 fully automatic with backwash fresh water flush – 150Ltr/hr (in lieu of Newport 400) ANCHOR UPGRADE
Stainless steel ULTRA anchor with flip swivel (in lieu of DELTA) ADDITIONAL FREEZER
2nd Vitrifrigo DW 100 BTX Freezer or fridge SPARES AND TOOLS
Tool cabinet instead of standard drawers or additional freezer Professional tool kit in foam inserts in tool cabinet Comprehensive spares kit Oil changers in each engine room DINGHY & OUTBOARD ENGINE
AB 12′ aluminum hull tender with Yamaha 25HP EFI outboard engine (inlcuding custom lifting bridles for dinghy davits) Custom built carbon fiber center console CUSTOMIZATION
10x Extra 110V plug outlet with multi socket and USB configuration inside boat, according to custom layout plan 1x Extra 110V Splash proof plug outlet with multi and European configuration in cockpit Extra iPad (for Air 3) docking station with sleeve on inboard side of stbd aft cabin – near the headboard Washer dryer fitted to custom island unit in galley Increase anchor chain from the standard 75m to 90m Supply and fit one extra (3rd) Composite gas cylinder with facility to secure in gas locker with strap Fit 32″ TV on manual custom manufactured sliding and rotating system next to galley fridge Convert TV cabinet into storage cupboard with doors opening towards fridge/freezer. Corian countertop Upgrade to 24V system (winches, windlass, toilets, lights, chargers, inverters, batteries, fans, davit motors, fridges, water maker, 24/12 DC/DC converter, emergency 12V switch, etc.) AFTER 2021
INSTRUMENTS AT HELP
1 additional Garmin GMI20 multi display instrument at helm 1 x GHC20 autopilot display at helm 1 Pilot Remote INSTRUMENTS AT NAV STATION
1 additional Garmin GMI20 multi display instrument at nav station 1 x GHC20 autopilot display at nav station ELECTRICAL
220V outlets everywhere there is an 110v Outlet (16 Outlets) The 220V/50Hz Iverter replaced with 3,5KW MassCombi Solar Panels Maxeon 3 x 420 Watt on an aluminium structure over the dingy Addition 1 x 60 Amp Mastervolt MPPT solar regulator Circuit to run the water heater off the 220v System VARIOUS
Wingaker – 212m² with Easy Snuffer and Cruising bag and Bot Name on the Sail Flexiteek on the stern and stern steps Salt water faucet in Galley Hull & Appendages
The hull is of sandwich composite construction using Quadriaxial stitched fabrics, Divinicell composite PVC foam and Epoxy Vinyl Ester resin. This gives a stiff laminate with excellent strength and lightweight properties. The engine beds are of GRP and bonded to the hull. Sea-cocks under water line are Marelon and located in accessible positions. Hose connections to inboard side of stainless steel sea-cocks have two stainless steel hose clamps. For osmosis protection an ISO / NPG Gelcoat is used Standard Gelcoat colour is white. Rudders are solid GRP boasting a 55mm solid stainless steel shaft with hydraulic steering system. Structural bulkheads are of Lloyds Marine ply wood construction and hand laminated to hull and deck. Bulkhead thickness is 24mm. Dedicated collision bulkheads at bow, at transom (to protect the engines) and at the bottom section of each keel Underwater epoxy- Antifouling application Deck & Fittings
The deck is of sandwich composite construction using Quadriaxial-stitched fabrics with end grain Balsa of appropriate thickness as the core High density material under all deck fittings with stainless steel backing plates. Deck surface has a moulded diamond patterned non-slip finish. Standard Gelcoat colour is white. Electric under deck horizontal anchor windlass 12v 1500 watt with wired remote in foredeck anchor locker. Large anchor cleat mounted in anchor locker. Stainless steel anchor swivel with twin nylon anchor roller inside anchor locker. Anchor – Ultra 45kg, 75m of 10mm chain, 100m 16mm warp (was 50m before) Stainless steel shroud chain plates are bolted to hull in area of structural bulkheads. Two recessed water tank fillers fitted on coachroof so as to act as rain water collection points Two Diesel fillers fitted on aft top transom step Breathers exit above deck level. 2 x 110v Electricity dock inlets on transom with shore power leads 1 x 220v Electricity dock inlet on transom with shore power lead Electrical stainless steel gooseneck at mast. Furling line lead blocks leading control lines back to cockpit Fore deck hatches for storage with recessed and lockable stainless steel catches with stainless steel gas struts Large access opening deck hatch on port foredeck peak gives access to white flow coated locker with ladder going down into locker. Cabin windows, non-opening, in tinted glass. Two x 5kg composite gas bottles with LP regulator and pressure gauge in self-ventilating gas locker in cockpit seat. Steaming lights on crossbeam A-frame, mast and aft targa Stainless steel toe rail covering hull deck bond. Two pull-pits with white moulded GRP seats Side railings with mid gate in solid stainless steel tubing with middle stainless steel wire. Railing height 720mm 8 x Large mooring cleats for marina berthing. 2 x Transom cleats on inner hull Roller furling self tacking Jib with curved traveller situated in front of mast step with furler control line and jib sheet led aft to winch in cockpit Complete main-sheeting system with blocks led aft to winch in cockpit. All lines from mast and sailing gear led aft in recessed deck moulding with cover plates Sliding aluminium entrance door with 6.5mm laminated clear glass with lock Recessed sliding door grating in cockpit floor. Fire extinguisher in cockpit Wet and dry lockers in cockpit for storage. Large teak cockpit table incorporating world map in black polyurethane on fixed aluminum legs . Small teak cockpit table on adjustable single aluminum leg enabling to be converted to a bed Wet bar in cockpit incorporating solid surfacing counter top with under mounted GRP sink and mixer tap Fridge for cockpit – Vitrifrigo C 60iX 60Ltr Drinks cupboard with shelves and bottle storage in wet bar with acrylic door and LED lights Overhead recessed LED cockpit lights Blue exterior courtecy floor lighting X5 LED backlit corporate logo on bulkhead in cockpit All lockers are self-draining and flow coated white One anodized aluminium structural cross beam with A-frame through bolted on bow. Two large open net trampolines lashed to deck. Stainless steel swimming ladder on Port side with stainless steel handrail up each stepped transom. Integral complete overhead targa bar with soft furnishing inserts Build into the targa on port side a overhead shower with hot and cold water Bimini sides and back with mesh windows that can also be closed for privacy, fitted in a recess in overhead moulding for flush look Recliner style sunbed on aft deck incorporating stowage underneath – stainless steel railing/cable to prevent person falling overboard 1 x 12 volt outlet at cockpit table 1 x 110 volt splash proof outlet at cockpit table 14 x large, non-opening recessed windows in tinted glass in hull outer sides Cockpit and helm cushions including backrests Davits on aft sunbed with remote controlled electric winches fitted in sunbed locker. Ropes and blocks included. (Manual override and radio remote controller) Helm Station
All lines led back to helm for easy single handed sailing Winches are 2 speed electric self tailing, size 60 14 x rope clutches at helm station for clutching sheets, halyards and ropes Extra large double seat helm chair with padded backrest in cockpit Large power dampened compass ahead of helm station in cockpit. 1 x Garmin GMI20 multi display instrument at helm 1 x Garmin 16″ 8416XSV GPSMAP chart plotter with GPS and remote keypad (UPGRADED) 1 x Garmin GMR 24X HD 36 mile – 4KW radar 1 x Garmin autopilot – GHP reactor 12 core pack with GHC20 display 1 x Garmin GHS10 wired command mike Glass windscreen and extended sliding cloth bimini above helm chair Separate moulded instrument module with angled mounting surfaces for instruments and incorporated cup holder Storage locker with lid for ropes below steering wheel C-Zone switch panel to control various systems from helm 1 x 12V outlet and 1 x USB outlet Second control with chain counter for windlass operation at cockpit Engine instrumentation, electronic throttle and gear controls 800mm, Black composite three spoke race look helm wheel Rigging & Sails
Spars by Sparcraft S.A. Spars built of extruded aluminium and anodised silver-grey. Single spreader fractional rig with internal wiring shielded in PVC tube secured to mast. Mast grounded through shrouds/chain plates to copper grounding plates in keels Batten car system for mainsail Boom, standing and running rigging. Shrouds have chafe guards Flag halyards from bottom spreader Furling system for headsails. Navigation, deck and anchor lights VHF aerial on top of mast. Sails by North Sails – Full batten mainsail with three reefs totalling 100m² Stack pack with corporate logo. 2 x mainsail lazy-Jacks 1 x mainsail halyard – 12mm Spectra 1 x Reacher furler halyard – 8mm 7×19 wire with short braid section and sliding adjuster on mast 1 x Jib furler halyard – 8mm 7×19 wire with short braid section and sliding adjuster on mast 1 x Spinnaker halyard -12mm Spectra 1 x Self tacking Jib sheet – 12mm Spectra 1 x Main boom topping lift – 12mm Braid 1 x Mainsheet sheet -12mm Spectra 1 x Reefline no1 – 12mm Spectra 1 x Reefline no2 – 12mm Spectra 1 x Reefline no3 – 12mm Spectra 1 x Fixed outhaul – 12mm Spectra 2 x Mainsail traveller car control lines – 10mm braid 2 x Reacher sheets – 14mm Spectra Furling 36m² Self taking Jib with UV including deck hardware Furling 83m² Reacher with UV including deck hardware 1 x Reacher furling line – 10mm Spectra Braid 1 x Jib furling line – 10mm Spectra Braid Interior Finishes
All joinery work and finishing in the living areas is done in accordance with the best yacht practice, using first-grade marine materials. All Veneer and solid wood are of V20 Oak limed wash 178.42 with a matt polyurethane acrylic lacquer for a professional and durable finish. Interior of all cupboards where possible have lined or painted surface Ceilings and topside linings in light cream soft touch leather furnishings Dark brown/grey plastic laminated hi wear flooring throughout Cabin mattresses is 120mm– multilayer foam with several densities covered with fabric. Basin units, basins and galley tops made from Corian solid surfacing Saloon
Large saloon area with 360 degree panoramic view U-shaped settee with cloth upholstery Large, convertable saloon table with internal 110V outlet for printer Combination shade-mosquito screens for opening deck hatches – Goiot Pleated blinds for saloon cabin windows Storage compartments under saloon seating Overhead stylish LED recessed ceiling lights. Light switches to operate and dim light output 3 x large opening deck hatches Locking Sliding aluminium door with open/closed positions (Titanium finish) Escape hatch in saloon floor with sand blasted glass ‘world map’ logo Sliding window to cockpit. Laminated flooring throughout. 110V outlets 1 x Cabin fan 2 x 12 000 BTU air con units with outlets at nav and settee Entertainment Area
Large U-shaped cupboard unit with entertainment equipment and storage drawers 1 x 40″ LED smart television with built in media player on TV lift system Large vertical cupboard housing refrigiration/freezer unit with small storage cupboard on the side 12v compressor driven door fridge-capacity 157L combined with a 2 drawer deep freezer – capacity 144L with incorporated ice maker Galley & Pantry
Galley in main saloon to Port with direct access to cockpit Large L- shaped counter top in solid surfacing with double under counter sink with chromed professional mixer tap Large double drawers under sink unit with heavy duty drawer slides Integrated dish draining area. Large cupboard doors with storage One set of drawers. Drawer for spice and condiments Rubbish bin in dedicated drawer for easy access Four-burner gas hob with flame failure device and pot holders. Extraction system above hob Speed oven with grill (convection microwave) Large Island unit with solid surfacing Large single cupboard Recessed overhead LED lighting. Light switch and dimmer for overhead lighting Electronic Gas shut off valve/alarm with 1 x sniffer Laminated flooring. Numerous 110v outlets Fire extinguisher Fire blanket Navigation Station
Situated in port front section of saloon and forward facing. Very good 360 degree visibility due to large cabin windows Mounted in a console is a custom designed switchboard with digital switching switches and digital battery monitoring system L-shaped nav desk with large countertop Numerous cupboards with doors and drawers. 1 x 110v outlet and 1 x 110v outlet with USB 1 x 12 volt outlet Chart light Overhead recessed LED lighting Fire extinguisher 1 x Garmin 300 VHF radio with AIS receiver 1 x Fusion MS IP 700i series music system with 4 x MS-FR7021 7″ 260watt marine speakers (two in saloon and two in cockpit) Office chair at navigation station i Pad with LaunchPort docking station and sleeve Le Grand USB (x3) outlet fitted to dashboard 1 x Cabin fan Guest Cabins
Access to each of the cabins is from the saloon by a companionway. Privacy is provided by a cabin door leading to each cabin Large 1.95m x 1.4m bed with soft furnished headboard. Island style bed with steps up each side giving separate access. Recessed bookshelf with cabinet and wardrobe Extra large storage under bed with drawers Dressing table with drawers underneath. Overhead opening deck hatch for ventilation Combination shade-mosquito screens for opening deck hatches – Goiot Several large non opening hull windows. Reading lights, overhead recessed ceiling lights, all LED Switch for cabin lights Fire extinguisher Laminated flooring throughout. 110v outlets with 1 x USB outlet close to bed 1 x Cabin fan (each cabin) Pleated blinds for hull cabin windows 1 x 8000 BTU air con unit (per cabin) with one upper level outlet for each cabin Guest En-suite Bathrooms
Bathroom enclosed with clear acrylic with sandblast vinyl design and dual pupose door Electric toilet Solid surfacing counter top with integrated washbasin Pressurized hot and cold water professional mixer tap. Cupboard and storage underneath Overhead mirror unit with storage for bathroom accessories Opening deck hatch for ventilation. Combination shade-mosquito screens for opening deck hatches – Goiot Opening Area 1 non opening port light Towel rail, soap holder and tiolet paper holder Owners En-suite Bathroom
Access to the owners hull is from the saloon by a companionway and privacy is provided by a large wooden sliding door Large solid surfacing counter top with integral “his” and “hers” double basins. Professional hot and cold mixer taps Cupboards underneath for storage Large mirror units above with storage for bathroom accessories Electric toilet 110V waterproof outlet Washer drier mounted in dedicated cupboard with removable shelves above A fully enclosed large shower moulding with Acrylic opening door and seat Opening deck hatch for ventilation. Combination shade-mosquito screens for opening deck hatches – Goiot Large non opening hull window Towel rail, soap holder and toilet paper holder Overhead recessed LED lighting Extra large dressing table with built in desk with drawers 110v outlets with 1 x USB outlet close to bed Extra large wardrobes with hanging locker and shelves Electronic safe installed in main wardrobe Large Dresser unit with cupboards for storage Double settee/lounger with storage underneath King-size 1.95m x 1.4m bed with soft furnished headboard. Island style bed with steps up each side giving separate access. 4 x large non opening vertical windows on outboard hull next to bed giving lots of light and vision Pleated blinds for hull cabin windows Extra large storage under bed with drawers Recessed bookshelf with shelf and cupboards on inboard side next to bed Overhead opening deck hatch Light switch and for cabin lights 1x Cabin fan 1x 12 000 BTU air con unit with two upper level outlets 2x Fire extinguishers Engines & Engine Room
Access to the engine rooms is via 2 specially moulded large hatches in the aft cockpit floor. These hatches are lockable and feature gas struts Two x Yanmar Marine diesel engines Model 4JH80-TE (80HP at 3200RPM) with SD60-T sail drive units, both freshwater cooled, Stbd side coupled via the heat exchanger to a 60L Calorifier for hot water. Each engine is mounted on a specially moulded bed. Complete passive ventilation system Wet exhaust system including water trap, gooseneck and anti-siphon. Yanmar fixed 3 blade propeller Fuel capacity is 790L, 2 x tanks, 1 for each engine with shut off valve. Fuel transfer pump to transfer fuel from one tank to another Fuel filter/water separator in each engine room Fuel tanks vented to deck via a breather with flame arrestor. Both engines start from a dedicated engine starting battery mounted in a each engine room. Overhead LED lights in each engine compartment. 2 x 120amp standard alternators fitted by engine manufacturer Engine room soundproofed (new improved system) Fireboy automatic fire extinguishing system in each engine room 2 x Large capacity bilge pump with hi-water alarm in each engine room Emergency tiller arm supplied on dedicated brackets in stbd engine room. Toolbox with assorted tools Plumbing
All freshwater hoses of re-enforced PVC tubing with “speed fit” connections. All hot water piping enclosed in a neoprene covering to maintain temperature over long periods of time 860 L rigid polyethylene water tanks in front lockers for easy removal and cleaning. Tank vents terminate on deck One water heater of 60lt with 110V resistor element. Complete with strainers, check valves and accumulator tank. All grey water from showers is discharged overboard by a automatic drain pump Two large capacity water pressure pumps mounted in front lockers near water tanks with accumulator tank Each pump draws water from the appropriate fresh water tank and service the entire boat. 100 Ltr/26.42 US gal/min manual bilge pump, one for each hull. Outlets are above water level and discharge overboard. Holding tanks for 3 x toilets. 4 x hi capacity electric bilge pumps with automatic sensors for main bilge area. Washer drier in forward area of stbd heads. Laundry area includes removable shelves at back of washer dryer. Water maker – Newport 400 NP-MK II-400S fully automatic with backwash/fresh water flush – 62Ltr + Connect Controller (new digital controller panel) Dishwasher – 45cm D/Washer – 10 place setting Connection for hose to hose down chain in windlass locker Fresh water filter for ice maker fitted in cupboard next to fridge Electrical
On board DC electrics are 12V with two wire-insulated return. Wires are sized to minimize voltage drop. All light current wiring is silicon tinned wiring which is flame proof and does not give off toxic vapours All light current conductors carrying an excess of 50 Amps are 50-70mm². All light current conductors programmed and powered by C-Zone digital switching Batteries – the ship’s auxiliary load consists of 6 x 1000 Ahr 2V Gel batteries A separate battery is supplied for engine starting. For good heavy current termination, copper tinned bus bars are used. A comprehensive DC main digital switching switch panel is located in the Nav Station. Mastervolt Easyview for battery status monitoring AC circuit – including shore power inlet sockets, shore power cord, electrical panel with necessary breakers and earth leakage. Euro American 2 pin and universal style AC outlets with USB facility fitted at various locations on the vessel 2 x large under water Zinc anodes fitted to hull. DC and AC are common grounded. Zinc saver Charger – 1x Mastervolt Chargmaster 24/100-3 100amp battery charger Genset – Fischer Panda 15000i PMS – 12KW/15KVA variable speed Invertor Charger – Mastervolt Mass Combi 24/4000W-100, 120V/60HZ Solar panels – 6x 145 Watt on saloon coachroof with 1 x 60 Amp Mastervolt MPPT solar regulator Safety Equipment
8 fenders / 10 x 10m 18mm tie up ropes Category 1 offshore safety equipment including 8 man life raft – Viking
-
LAYOUT
OWNER VERSION – 3x cabins and 3x en-suite heads/bathrooms Specifications
Length overall 15.44 m 50.64 ft Length waterline 15.15 m 49.69 ft Beam 8 m 24.24 ft Draft 1.35 m 4.43 ft Bridge deck clearance Light Craft 1 m 3.28 ft Mast height above waterline 24 m 78.72 ft Sail Area
Sail Area – Mainsail 100 m² 1076 sf Sail Area-Reacher 83 m² 893 sf Sail Area-Jib 36 m² 387 sf Engines 2 x 80 HP 2 x 80 HP Fresh water (4 x 215Ltr tanks) 860 Ltr 226 gal Diesel (2 x 395Ltr tanks) 790 Ltr 208 gal CE Certified Category A Category A Displacement (mlcc) 21000 kg 46200 lbs UNIQUE EXTRAS
COMFORT PACKAGE
Gas BBQ on transom Cotton pascale, quilted double bed fitted mattress protectors Fendertex – inflatable fenders with custom logo (8 units) Canopy shade for foredeck and 2x large bean bacg (or foldable deck seats) Four button remote for C-Zone system ELECTRONICS UPGRADE
Additional 2nd Garmin GMI 20 repeater screen at inside nav station Garmin AIS 600 transceiver (receiver is standard) Garmin forward looking sounder Hailer installed on spreaders and connected to VHF radio Garmin Sirius XM receiver (USA only) ELECTRICAL UPGRADE
Batteries upgrade to 1080 Ah Li-ion Additional 900W solar panels with separate Mastervolt MPPT charge controller fitted on targa ENTERTAINMENT PACKAGE
Colour television – 3x Samsung 32″ LED TV’s in cabins 1x TV in master cabin Bose home theater sound system in saloon 2x Bose speakers to be fitted on spreaders 4 x Underwater LED lights COMMUNICATIONS PACKAGE
Cellular Modem / WiFi Router Antenna System Iridium Go with external aerial on spreader SATELLITE TV SYSTEM
KVH TV5 satellite TV system SATELLITE BROADBAND INTERNET SYSTEM
KVH TracPhone V3ip antenna system FLEXITEEK DECKING
Flexiteek on cockpit floor, steps to helm station and helm station floor (Estimtated at 50% of total area) DOWNWIND SAIL
Wingaker – 212m² with Easy Snuffer and Cruising bag (Pre-install blocks only) PROPELLER UPGRADE
Gori 3 blade folding propellers with rope cutters WINCH UPGRADE
Harken 3 speed electric winches (in lieu of 2 speed) WATERMAKER UPGRADE
Water maker – Newport NP-MK IIZ-1000 fully automatic with backwash fresh water flush – 150Ltr/hr (in lieu of Newport 400) ANCHOR UPGRADE
Stainless steel ULTRA anchor with flip swivel (in lieu of DELTA) ADDITIONAL FREEZER
2nd Vitrifrigo DW 100 BTX Freezer or fridge SPARES AND TOOLS
Tool cabinet instead of standard drawers or additional freezer Professional tool kit in foam inserts in tool cabinet Comprehensive spares kit Oil changers in each engine room DINGHY & OUTBOARD ENGINE
AB 12′ aluminum hull tender with Yamaha 25HP EFI outboard engine (inlcuding custom lifting bridles for dinghy davits) Custom built carbon fiber center console CUSTOMIZATION
10x Extra 110V plug outlet with multi socket and USB configuration inside boat, according to custom layout plan 1x Extra 110V Splash proof plug outlet with multi and European configuration in cockpit Extra iPad (for Air 3) docking station with sleeve on inboard side of stbd aft cabin – near the headboard Washer dryer fitted to custom island unit in galley Increase anchor chain from the standard 75m to 90m Supply and fit one extra (3rd) Composite gas cylinder with facility to secure in gas locker with strap Fit 32″ TV on manual custom manufactured sliding and rotating system next to galley fridge Convert TV cabinet into storage cupboard with doors opening towards fridge/freezer. Corian countertop Upgrade to 24V system (winches, windlass, toilets, lights, chargers, inverters, batteries, fans, davit motors, fridges, water maker, 24/12 DC/DC converter, emergency 12V switch, etc.) AFTER 2021
INSTRUMENTS AT HELP
1 additional Garmin GMI20 multi display instrument at helm 1 x GHC20 autopilot display at helm 1 Pilot Remote INSTRUMENTS AT NAV STATION
1 additional Garmin GMI20 multi display instrument at nav station 1 x GHC20 autopilot display at nav station ELECTRICAL
220V outlets everywhere there is an 110v Outlet (16 Outlets) The 220V/50Hz Iverter replaced with 3,5KW MassCombi Solar Panels Maxeon 3 x 420 Watt on an aluminium structure over the dingy Addition 1 x 60 Amp Mastervolt MPPT solar regulator Circuit to run the water heater off the 220v System VARIOUS
Wingaker – 212m² with Easy Snuffer and Cruising bag and Bot Name on the Sail Flexiteek on the stern and stern steps Salt water faucet in Galley Hull & Appendages
The hull is of sandwich composite construction using Quadriaxial stitched fabrics, Divinicell composite PVC foam and Epoxy Vinyl Ester resin. This gives a stiff laminate with excellent strength and lightweight properties. The engine beds are of GRP and bonded to the hull. Sea-cocks under water line are Marelon and located in accessible positions. Hose connections to inboard side of stainless steel sea-cocks have two stainless steel hose clamps. For osmosis protection an ISO / NPG Gelcoat is used Standard Gelcoat colour is white. Rudders are solid GRP boasting a 55mm solid stainless steel shaft with hydraulic steering system. Structural bulkheads are of Lloyds Marine ply wood construction and hand laminated to hull and deck. Bulkhead thickness is 24mm. Dedicated collision bulkheads at bow, at transom (to protect the engines) and at the bottom section of each keel Underwater epoxy- Antifouling application Deck & Fittings
The deck is of sandwich composite construction using Quadriaxial-stitched fabrics with end grain Balsa of appropriate thickness as the core High density material under all deck fittings with stainless steel backing plates. Deck surface has a moulded diamond patterned non-slip finish. Standard Gelcoat colour is white. Electric under deck horizontal anchor windlass 12v 1500 watt with wired remote in foredeck anchor locker. Large anchor cleat mounted in anchor locker. Stainless steel anchor swivel with twin nylon anchor roller inside anchor locker. Anchor – Ultra 45kg, 75m of 10mm chain, 100m 16mm warp (was 50m before) Stainless steel shroud chain plates are bolted to hull in area of structural bulkheads. Two recessed water tank fillers fitted on coachroof so as to act as rain water collection points Two Diesel fillers fitted on aft top transom step Breathers exit above deck level. 2 x 110v Electricity dock inlets on transom with shore power leads 1 x 220v Electricity dock inlet on transom with shore power lead Electrical stainless steel gooseneck at mast. Furling line lead blocks leading control lines back to cockpit Fore deck hatches for storage with recessed and lockable stainless steel catches with stainless steel gas struts Large access opening deck hatch on port foredeck peak gives access to white flow coated locker with ladder going down into locker. Cabin windows, non-opening, in tinted glass. Two x 5kg composite gas bottles with LP regulator and pressure gauge in self-ventilating gas locker in cockpit seat. Steaming lights on crossbeam A-frame, mast and aft targa Stainless steel toe rail covering hull deck bond. Two pull-pits with white moulded GRP seats Side railings with mid gate in solid stainless steel tubing with middle stainless steel wire. Railing height 720mm 8 x Large mooring cleats for marina berthing. 2 x Transom cleats on inner hull Roller furling self tacking Jib with curved traveller situated in front of mast step with furler control line and jib sheet led aft to winch in cockpit Complete main-sheeting system with blocks led aft to winch in cockpit. All lines from mast and sailing gear led aft in recessed deck moulding with cover plates Sliding aluminium entrance door with 6.5mm laminated clear glass with lock Recessed sliding door grating in cockpit floor. Fire extinguisher in cockpit Wet and dry lockers in cockpit for storage. Large teak cockpit table incorporating world map in black polyurethane on fixed aluminum legs . Small teak cockpit table on adjustable single aluminum leg enabling to be converted to a bed Wet bar in cockpit incorporating solid surfacing counter top with under mounted GRP sink and mixer tap Fridge for cockpit – Vitrifrigo C 60iX 60Ltr Drinks cupboard with shelves and bottle storage in wet bar with acrylic door and LED lights Overhead recessed LED cockpit lights Blue exterior courtecy floor lighting X5 LED backlit corporate logo on bulkhead in cockpit All lockers are self-draining and flow coated white One anodized aluminium structural cross beam with A-frame through bolted on bow. Two large open net trampolines lashed to deck. Stainless steel swimming ladder on Port side with stainless steel handrail up each stepped transom. Integral complete overhead targa bar with soft furnishing inserts Build into the targa on port side a overhead shower with hot and cold water Bimini sides and back with mesh windows that can also be closed for privacy, fitted in a recess in overhead moulding for flush look Recliner style sunbed on aft deck incorporating stowage underneath – stainless steel railing/cable to prevent person falling overboard 1 x 12 volt outlet at cockpit table 1 x 110 volt splash proof outlet at cockpit table 14 x large, non-opening recessed windows in tinted glass in hull outer sides Cockpit and helm cushions including backrests Davits on aft sunbed with remote controlled electric winches fitted in sunbed locker. Ropes and blocks included. (Manual override and radio remote controller) Helm Station
All lines led back to helm for easy single handed sailing Winches are 2 speed electric self tailing, size 60 14 x rope clutches at helm station for clutching sheets, halyards and ropes Extra large double seat helm chair with padded backrest in cockpit Large power dampened compass ahead of helm station in cockpit. 1 x Garmin GMI20 multi display instrument at helm 1 x Garmin 16″ 8416XSV GPSMAP chart plotter with GPS and remote keypad (UPGRADED) 1 x Garmin GMR 24X HD 36 mile – 4KW radar 1 x Garmin autopilot – GHP reactor 12 core pack with GHC20 display 1 x Garmin GHS10 wired command mike Glass windscreen and extended sliding cloth bimini above helm chair Separate moulded instrument module with angled mounting surfaces for instruments and incorporated cup holder Storage locker with lid for ropes below steering wheel C-Zone switch panel to control various systems from helm 1 x 12V outlet and 1 x USB outlet Second control with chain counter for windlass operation at cockpit Engine instrumentation, electronic throttle and gear controls 800mm, Black composite three spoke race look helm wheel Rigging & Sails
Spars by Sparcraft S.A. Spars built of extruded aluminium and anodised silver-grey. Single spreader fractional rig with internal wiring shielded in PVC tube secured to mast. Mast grounded through shrouds/chain plates to copper grounding plates in keels Batten car system for mainsail Boom, standing and running rigging. Shrouds have chafe guards Flag halyards from bottom spreader Furling system for headsails. Navigation, deck and anchor lights VHF aerial on top of mast. Sails by North Sails – Full batten mainsail with three reefs totalling 100m² Stack pack with corporate logo. 2 x mainsail lazy-Jacks 1 x mainsail halyard – 12mm Spectra 1 x Reacher furler halyard – 8mm 7×19 wire with short braid section and sliding adjuster on mast 1 x Jib furler halyard – 8mm 7×19 wire with short braid section and sliding adjuster on mast 1 x Spinnaker halyard -12mm Spectra 1 x Self tacking Jib sheet – 12mm Spectra 1 x Main boom topping lift – 12mm Braid 1 x Mainsheet sheet -12mm Spectra 1 x Reefline no1 – 12mm Spectra 1 x Reefline no2 – 12mm Spectra 1 x Reefline no3 – 12mm Spectra 1 x Fixed outhaul – 12mm Spectra 2 x Mainsail traveller car control lines – 10mm braid 2 x Reacher sheets – 14mm Spectra Furling 36m² Self taking Jib with UV including deck hardware Furling 83m² Reacher with UV including deck hardware 1 x Reacher furling line – 10mm Spectra Braid 1 x Jib furling line – 10mm Spectra Braid Interior Finishes
All joinery work and finishing in the living areas is done in accordance with the best yacht practice, using first-grade marine materials. All Veneer and solid wood are of V20 Oak limed wash 178.42 with a matt polyurethane acrylic lacquer for a professional and durable finish. Interior of all cupboards where possible have lined or painted surface Ceilings and topside linings in light cream soft touch leather furnishings Dark brown/grey plastic laminated hi wear flooring throughout Cabin mattresses is 120mm– multilayer foam with several densities covered with fabric. Basin units, basins and galley tops made from Corian solid surfacing Saloon
Large saloon area with 360 degree panoramic view U-shaped settee with cloth upholstery Large, convertable saloon table with internal 110V outlet for printer Combination shade-mosquito screens for opening deck hatches – Goiot Pleated blinds for saloon cabin windows Storage compartments under saloon seating Overhead stylish LED recessed ceiling lights. Light switches to operate and dim light output 3 x large opening deck hatches Locking Sliding aluminium door with open/closed positions (Titanium finish) Escape hatch in saloon floor with sand blasted glass ‘world map’ logo Sliding window to cockpit. Laminated flooring throughout. 110V outlets 1 x Cabin fan 2 x 12 000 BTU air con units with outlets at nav and settee Entertainment Area
Large U-shaped cupboard unit with entertainment equipment and storage drawers 1 x 40″ LED smart television with built in media player on TV lift system Large vertical cupboard housing refrigiration/freezer unit with small storage cupboard on the side 12v compressor driven door fridge-capacity 157L combined with a 2 drawer deep freezer – capacity 144L with incorporated ice maker Galley & Pantry
Galley in main saloon to Port with direct access to cockpit Large L- shaped counter top in solid surfacing with double under counter sink with chromed professional mixer tap Large double drawers under sink unit with heavy duty drawer slides Integrated dish draining area. Large cupboard doors with storage One set of drawers. Drawer for spice and condiments Rubbish bin in dedicated drawer for easy access Four-burner gas hob with flame failure device and pot holders. Extraction system above hob Speed oven with grill (convection microwave) Large Island unit with solid surfacing Large single cupboard Recessed overhead LED lighting. Light switch and dimmer for overhead lighting Electronic Gas shut off valve/alarm with 1 x sniffer Laminated flooring. Numerous 110v outlets Fire extinguisher Fire blanket Navigation Station
Situated in port front section of saloon and forward facing. Very good 360 degree visibility due to large cabin windows Mounted in a console is a custom designed switchboard with digital switching switches and digital battery monitoring system L-shaped nav desk with large countertop Numerous cupboards with doors and drawers. 1 x 110v outlet and 1 x 110v outlet with USB 1 x 12 volt outlet Chart light Overhead recessed LED lighting Fire extinguisher 1 x Garmin 300 VHF radio with AIS receiver 1 x Fusion MS IP 700i series music system with 4 x MS-FR7021 7″ 260watt marine speakers (two in saloon and two in cockpit) Office chair at navigation station i Pad with LaunchPort docking station and sleeve Le Grand USB (x3) outlet fitted to dashboard 1 x Cabin fan Guest Cabins
Access to each of the cabins is from the saloon by a companionway. Privacy is provided by a cabin door leading to each cabin Large 1.95m x 1.4m bed with soft furnished headboard. Island style bed with steps up each side giving separate access. Recessed bookshelf with cabinet and wardrobe Extra large storage under bed with drawers Dressing table with drawers underneath. Overhead opening deck hatch for ventilation Combination shade-mosquito screens for opening deck hatches – Goiot Several large non opening hull windows. Reading lights, overhead recessed ceiling lights, all LED Switch for cabin lights Fire extinguisher Laminated flooring throughout. 110v outlets with 1 x USB outlet close to bed 1 x Cabin fan (each cabin) Pleated blinds for hull cabin windows 1 x 8000 BTU air con unit (per cabin) with one upper level outlet for each cabin Guest En-suite Bathrooms
Bathroom enclosed with clear acrylic with sandblast vinyl design and dual pupose door Electric toilet Solid surfacing counter top with integrated washbasin Pressurized hot and cold water professional mixer tap. Cupboard and storage underneath Overhead mirror unit with storage for bathroom accessories Opening deck hatch for ventilation. Combination shade-mosquito screens for opening deck hatches – Goiot Opening Area 1 non opening port light Towel rail, soap holder and tiolet paper holder Owners En-suite Bathroom
Access to the owners hull is from the saloon by a companionway and privacy is provided by a large wooden sliding door Large solid surfacing counter top with integral “his” and “hers” double basins. Professional hot and cold mixer taps Cupboards underneath for storage Large mirror units above with storage for bathroom accessories Electric toilet 110V waterproof outlet Washer drier mounted in dedicated cupboard with removable shelves above A fully enclosed large shower moulding with Acrylic opening door and seat Opening deck hatch for ventilation. Combination shade-mosquito screens for opening deck hatches – Goiot Large non opening hull window Towel rail, soap holder and toilet paper holder Overhead recessed LED lighting Extra large dressing table with built in desk with drawers 110v outlets with 1 x USB outlet close to bed Extra large wardrobes with hanging locker and shelves Electronic safe installed in main wardrobe Large Dresser unit with cupboards for storage Double settee/lounger with storage underneath King-size 1.95m x 1.4m bed with soft furnished headboard. Island style bed with steps up each side giving separate access. 4 x large non opening vertical windows on outboard hull next to bed giving lots of light and vision Pleated blinds for hull cabin windows Extra large storage under bed with drawers Recessed bookshelf with shelf and cupboards on inboard side next to bed Overhead opening deck hatch Light switch and for cabin lights 1x Cabin fan 1x 12 000 BTU air con unit with two upper level outlets 2x Fire extinguishers Engines & Engine Room
Access to the engine rooms is via 2 specially moulded large hatches in the aft cockpit floor. These hatches are lockable and feature gas struts Two x Yanmar Marine diesel engines Model 4JH80-TE (80HP at 3200RPM) with SD60-T sail drive units, both freshwater cooled, Stbd side coupled via the heat exchanger to a 60L Calorifier for hot water. Each engine is mounted on a specially moulded bed. Complete passive ventilation system Wet exhaust system including water trap, gooseneck and anti-siphon. Yanmar fixed 3 blade propeller Fuel capacity is 790L, 2 x tanks, 1 for each engine with shut off valve. Fuel transfer pump to transfer fuel from one tank to another Fuel filter/water separator in each engine room Fuel tanks vented to deck via a breather with flame arrestor. Both engines start from a dedicated engine starting battery mounted in a each engine room. Overhead LED lights in each engine compartment. 2 x 120amp standard alternators fitted by engine manufacturer Engine room soundproofed (new improved system) Fireboy automatic fire extinguishing system in each engine room 2 x Large capacity bilge pump with hi-water alarm in each engine room Emergency tiller arm supplied on dedicated brackets in stbd engine room. Toolbox with assorted tools Plumbing
All freshwater hoses of re-enforced PVC tubing with “speed fit” connections. All hot water piping enclosed in a neoprene covering to maintain temperature over long periods of time 860 L rigid polyethylene water tanks in front lockers for easy removal and cleaning. Tank vents terminate on deck One water heater of 60lt with 110V resistor element. Complete with strainers, check valves and accumulator tank. All grey water from showers is discharged overboard by a automatic drain pump Two large capacity water pressure pumps mounted in front lockers near water tanks with accumulator tank Each pump draws water from the appropriate fresh water tank and service the entire boat. 100 Ltr/26.42 US gal/min manual bilge pump, one for each hull. Outlets are above water level and discharge overboard. Holding tanks for 3 x toilets. 4 x hi capacity electric bilge pumps with automatic sensors for main bilge area. Washer drier in forward area of stbd heads. Laundry area includes removable shelves at back of washer dryer. Water maker – Newport 400 NP-MK II-400S fully automatic with backwash/fresh water flush – 62Ltr + Connect Controller (new digital controller panel) Dishwasher – 45cm D/Washer – 10 place setting Connection for hose to hose down chain in windlass locker Fresh water filter for ice maker fitted in cupboard next to fridge Electrical
On board DC electrics are 12V with two wire-insulated return. Wires are sized to minimize voltage drop. All light current wiring is silicon tinned wiring which is flame proof and does not give off toxic vapours All light current conductors carrying an excess of 50 Amps are 50-70mm². All light current conductors programmed and powered by C-Zone digital switching Batteries – the ship’s auxiliary load consists of 6 x 1000 Ahr 2V Gel batteries A separate battery is supplied for engine starting. For good heavy current termination, copper tinned bus bars are used. A comprehensive DC main digital switching switch panel is located in the Nav Station. Mastervolt Easyview for battery status monitoring AC circuit – including shore power inlet sockets, shore power cord, electrical panel with necessary breakers and earth leakage. Euro American 2 pin and universal style AC outlets with USB facility fitted at various locations on the vessel 2 x large under water Zinc anodes fitted to hull. DC and AC are common grounded. Zinc saver Charger – 1x Mastervolt Chargmaster 24/100-3 100amp battery charger Genset – Fischer Panda 15000i PMS – 12KW/15KVA variable speed Invertor Charger – Mastervolt Mass Combi 24/4000W-100, 120V/60HZ Solar panels – 6x 145 Watt on saloon coachroof with 1 x 60 Amp Mastervolt MPPT solar regulator Safety Equipment
8 fenders / 10 x 10m 18mm tie up ropes Category 1 offshore safety equipment including 8 man life raft – Viking
